Design forum

Revit cells not working

Eric Milberger
Enthusiast

I have to create seating for a sports areana.  Typical theater seating.  A number of vendors but only one in the US has Revit files.



None of the others have anything and none in Europe even come close.



When I copy even one of there files into the Archicad model it shows great but cannot be plotted or translated into an IFC file.  I am at a loss and dead in the water and losing a client.



I need help quickly but don’t know where to find help.

Eric Milberger, Architect | Master Planner
Archicad 25
AecoSim
Microstation
Windows 10 64bit

Remote - i7-8550U CPU @ 1.80GHz, 2001 Mhz, 4 Core

Office - Processor i7-8700K CPU @ 3.70GHz, 3696 Mhz, 6 Core
6 REPLIES 6

Barry Kelly
Moderator

@Eric Milberger wrote:

When I copy even one of there files into the Archicad model it shows great but cannot be plotted or translated into an IFC file.


Is it a 3D model or just 2D drawings?

And what is a 'Revit Cell' - your title makes no sense.

Don't forget this is an Archicad forum.



Barry.




One of the forum moderators.
Versions 6.5 to 25
Dell XPS- i7-6700 @ 3.4Ghz, 16GB ram, GeForce GTX 960 (2GB), Windows 10
Dell Precision 3510 - i7 6820HQ @ 2.70GHz, 16GB RAM, AMD FirePro W5130M, Windows 10

That is correct and the world is a Revit world.

It is an RFA file which is the comparable to a 3D cell in generic language’



In this case it is a RFA item brought into Archicad. And needs to be duplicated a dozen times

But not even one works.  It looks great in hte model but crashes when trying to save as a ifc file or plot.

Eric Milberger, Architect | Master Planner
Archicad 25
AecoSim
Microstation
Windows 10 64bit

Remote - i7-8550U CPU @ 1.80GHz, 2001 Mhz, 4 Core

Office - Processor i7-8700K CPU @ 3.70GHz, 3696 Mhz, 6 Core

So by saying 'Cell' you actually mean 'Object'?



There was no mention in your original post that it was an RFA object or that Archicad was crashing.



I assume you are using the 'Import RFA to GDL object' add-on to import the seating?

It could be that there is something in that RFA object that Archicad just does not like - they can become very big objects (file size wise).



Have you tried any other (smaller and less complicated) RFA files?



So it seems like you can actually import the RFA file.

Maybe then convert the GDL object into a morph.

See if that can now print and export as IFC.

You can always save it back as an object if you need to.

Maybe converting it to a morph will fix any problem geometry?

I don't know if it will work, but it is worth a try.



Also make sure Archicad is up to date with the latest build (6000 I believe).



Other than that, if you have a support agreement, you could maybe ask your local Archicad support for help?





Barry.




One of the forum moderators.
Versions 6.5 to 25
Dell XPS- i7-6700 @ 3.4Ghz, 16GB ram, GeForce GTX 960 (2GB), Windows 10
Dell Precision 3510 - i7 6820HQ @ 2.70GHz, 16GB RAM, AMD FirePro W5130M, Windows 10

Lingwisyer
Legend

Without the context of AC, "3D Cell" to me would be an image of a cellular structure such as a protein or as everyone has seen sars-cov-2...



If any of the vendors had 3ds file, could you try running an optimise operation on it in MAX, then bringing that into AC.

AC22-23 AUS 7000
Self-taught, bend it till it breaks.
Win10 | R5 2600 | 16GB | GTX1660

Help Those Help You - Add a Signature
Creating a Thread

Djordje
Mentor

You are running out of resources.

The seat is too detailed, with too many polygons, and however good Archicad is in showing complex geometry, an area can be too much.

Try using the inbuilt theatre/stadium seating Archicad object (not cell, that might be the Microstation term?) for general layouting, and you can use the highly detailed RFA model for visualization close ups.

All this is in general because the problem is not easy to understand the way you have explained it, and this is my best guess...

... once upon a time, about 20 years ago, I wrote a small HowTo on converting the 3ds/DWG/DXF meshes to GDL on an example of a Mercedes GTR race car. The principle stays the same: take care of your polygons!!!!

To make sure it is the polygons, and not something nastier: Select that object in 3D window, and run PolyCount. Then you shall see.

Djordje



ArchiCAD since 4.55 ... 1995
HP Omen

Thank-you as that at least answered my question.

I know know I will require ModelPort for my projects.

Trying to find all I need to make things work.

Eric Milberger, Architect | Master Planner
Archicad 25
AecoSim
Microstation
Windows 10 64bit

Remote - i7-8550U CPU @ 1.80GHz, 2001 Mhz, 4 Core

Office - Processor i7-8700K CPU @ 3.70GHz, 3696 Mhz, 6 Core
