Generic Label 19 - Surface Area

Anonymous
Not applicable
I have used the Generic Label to report the ID and the Surface area of a composite Roof. It was reporting about 2 times as it should. I created a Fill of the same roof and the (normal to plan) area reported correctly. Since the roof surface is pitched (only 1:12 in this case) you could expect the actual surface area to be larger the area calculated by a fill which is normal (or perpendicular) to plan surface. Yet is reporting a bit over twice of what you would expect.
Also if would be beneficial to have the plan area reported for rainfall area calculations and not the sloped surface area.
5 REPLIES 5

Anonymous
Not applicable
Zoomed in to label and Area Fill area

Barry Kelly
Moderator
I haven't looked at it but I am wondering if the surface is simply give the total for all surfaces - top, bottom and sides?

Barry.

One of the forum moderators.
Versions 6.5 to 25
Dell XPS- i7-6700 @ 3.4Ghz, 16GB ram, GeForce GTX 960 (2GB), Windows 10
Dell Precision 3510 - i7 6820HQ @ 2.70GHz, 16GB RAM, AMD FirePro W5130M, Windows 10

Jay:

The parameter Value should have a selection arrow that allows this parameter to be changed from Entire Surface Area to Sum of Selected Surfaces, which then adds parameters for surfaces to be added to the total.

David
David Maudlin / Architect

www.davidmaudlin.com

Digital Architecture

AC26 USA • iMac 27" 4.0GHz Quad-core i7 | 24 gb ram • MacBook Pro 2.8GHz | 16 gb ram • OSX10.15.7

Anonymous
Not applicable
David it looks as if you have different options available in the surface area.

Anonymous
Not applicable
I was using AC19, yet the Library part was the Generic Label 18 from the Migrated library. I will attempt this using the Generic Label 19 with the adjustments you show.
